Delivery Cable Length

5m

Average Output Power

>100W

Maximum Pulse Energy

1.5mJ

Pulse Frequency Range

1-4000kHz

Pulse Width

2-500ns

Output Power Instability

<5%

Cooling Method

Air Cooled

Power Supply Voltage

48V

Power Consumption

<400W

Power supply current requirement

>8A

Central Wavelength

1064nm

Emission Bandwidth （FWHM）@3dB

<15nm

Polarization

Random

Anti-Reflection Protection

Yes

Output Beam Diameter

4.0±0.5mm，7.5±0.5mm（Customizable）

Output Power Tuning Range

0～100%

Ambient Temperature Range

0～40℃

Storage Temperature Range

-10～60℃

Dimensions

617*469*291mm

Weight

28  Kg
